SpecSeal SSC Intumescent Firestop Collar

SpecSeal SSC Intumescent Firestop Collar
SpecSeal SSC Intumescent Firestop Collar
SpecSeal SSC Intumescent Firestop Collar
SpecSeal SSC Intumescent Firestop Collar
SpecSeal SSC Intumescent Firestop Collar
SpecSeal SSC Intumescent Firestop Collar

SpecSeal SSC Intumescent Firestop Collar

SpecSeal SSC Firestop Collars are factory-manufactured firestop devices sized to plastic pipes of up to 6 in. Trade Size. SSC Collars consist of a restraining collar with a factory applied intumescent ensuring the correct amount of material is applied every time. Under fire exposure, SSC Collars quickly expand and collapse combustible piping forming a dense char, resisting the passage of smoke and flame.

Test Standards ASTM E814 (UL1479)
CAN/ULC-S115
CAN/ULC-S115 with 50 PA
Third Party Approvals

Features

  • Sized for 1-1/2, 2, 3, 4, 6 Trade Size Combustible Pipes
  • Installs quickly and eliminates waste
  • Tested to CAN/ULC-S115 at 50 PA (0.20 in. water)
  • Rapid expansion - closes off burning pipes quickly
  • Flexible & durable - no loose flakes (eye hazards)
  • Water resistant - no water soluble or hygroscopic ingredients
  • High volume char - expands up to 60 times
Applications
Plastic Pipe
Properties
Permanent
Finished Product
Intumescent
Low VOC

Specifications

Property Value
Available Sizes 1.5" (38mm), 2" (51mm), 3" (76mm), 4" (102mm), 6" (152mm)
Shell Construction Galvanized Steel
Expansion Begins 320°F (160°C)
Volume Expansion 32x to 64x (free expansion)
In Service Temperature Less than 120°F (49°C)
Shelf Life No Limit

Ordering Information

Catalog Number UPC Number Description (UOM) Qty. Case Qty. Weight (Each) Image
SSC150 730573031506 Intumescent Firestop Collars For 1.5” (38 mm) plastic pipe 1 6 0.33 lbs Intumescent Firestop Collars For 1.5” (38 mm) plastic pipe
SSC200 730573032008 Intumescent Firestop Collars For 2.0” (51 mm) plastic pipe 1 6 0.38 lbs Intumescent Firestop Collars For 2.0” (51 mm) plastic pipe
SSC300 730573033005 Intumescent Firestop Collars For 3.0” (76 mm) plastic pipe 1 6 0.74 lbs Intumescent Firestop Collars  For 3.0” (76 mm) plastic pipe
SSC400 730573034002 Intumescent Firestop Collars For 4.0” (102 mm) plastic pipe 1 6 1.07 lbs Intumescent Firestop Collars For 4.0” (102 mm) plastic pipe
SSC600 730573036006 Firestop Collar For 6.0" Diameter Plastic Pipe 1 2 5 lbs Firestop Collar For 6.0
SpecSeal SSC Intumescent Firestop Collar
