SpecSeal SSB Intumescent Firestop Pillows

SpecSeal SSB Intumescent Firestop Pillows
SpecSeal SSB Intumescent Firestop Pillows
SpecSeal SSB Intumescent Firestop Pillows
SpecSeal SSB Intumescent Firestop Pillows
SpecSeal SSB Intumescent Firestop Pillows
SpecSeal SSB Intumescent Firestop Pillows

SpecSeal SSB Intumescent Firestop Pillows

SpecSeal SSB Firestop Pillows easily compress and conform around any penetrant. Equally suited for new or existing conditions, SpecSeal Pillows make short work of even the most complex through-penetration firestop conditions.

Test Standards ASTM E90
ASTM E814 (UL1479)
ASTM G21
CAN/ULC-S115
Third Party Approvals

Features

  • Tested in a wide range of construction types and configurations
  • Easily installs from a single side
  • Re-enterable allowing for future work in previously sealed openings
Applications
Blank Openings
Busway
Cables
Cable Tray
Ductwork
Metallic Pipe
Multiple Penetrations
Plastic Pipe
Properties
Finished Product
Intumescent
Light Weight
Low VOC
No Expiration
Re-Enterable
STC Rating

Specifications

Property Value
Color Red
Density 4 pcf (64 kg/m³)
Flammability V-0*
Compression 25% to 33%**
Air Leakage Less than 1 CFM/sq ft
In Service Temperature Less than 130°F (54°C)
Storage Temperature Less than 130°F (54°C)
STC Rating (ASTM E 90-40) 60 (Relates to specific construction)
L Rating (UL1479 and CAN/ULC-S115) Less than 1 CFM/sq ft (Pillows Only)
VOC Content 0.00 lbs/gal (0.0 g/L)***
Notes *Outer poly bag **As installed ***Per SCAQMD Rule 1168 (EPA Method 24)

Ordering Information

Catalog Number UPC Number Description (UOM) Qty. Case Qty. Weight (Each) Image
SSB36 730573063606 SSB Intumescent Firestop Pillow 3"x6"x9" 1 16 0.55 lbs SSB Intumescent Firestop Pillow 3
SSB14 730573061404 SSB Intumescent Firestop Pillow 1"x4"x9" 1 20 0.19 lbs SSB Intumescent Firestop Pillow 1
SSB24 730573062401 SSB Intumescent Firestop Pillow 2"x4"x9" 1 10 0.31 lbs SSB Intumescent Firestop Pillow 2
SSB26 730573062609 SSB Intumescent Firestop Pillow 2"x6"x9" 1 22 0.39 lbs SSB Intumescent Firestop Pillow 2
